TBE-N1 COVERED CONCRETE SLEEPER

CONCRETE SLEEPER IN C.A.P. COVERED WITH ELASTOMERIC MATERIAL WITH LOW VIBRATION ATTENUATION, FOR INSTALLATION WITH ANCHORING JET IN CONCRETE.

Margaritelli Ferroviaria

For urban transport tracks with vibration damping requirements.
Compliant with EN 13230-1 / 2 standards and Technical Specifications
PN1210_06_ACT_STE_002207 (Grand Paris Express)


Length: 2200 mm
Width: 255 mm
Height under rail: 200 mm
Mass: 267 kg


Mk,r,pos ≥ +10,00 kNm positive design bending moment characteristic for the sub-rail section
Mk,c,neg ≥ -14,25 kNm negative design bending moment at center
